DBK PL-210 2-Way Linear Array Speaker

The DBK PL-210 is a passive two-way linear array speaker designed to deliver superior audio clarity and powerful sound reinforcement for professional applications. Its advanced acoustic engineering ensures optimal performance across a wide frequency range, making it ideal for live sound, touring, and fixed installations.

The frequency response of the PL-210 is meticulously tuned to cover LF 95–2000 Hz and HF 2000–20000 Hz, ensuring seamless transitions between the low and high-frequency drivers. This broad range captures every detail of the audio spectrum, from deep bass to crisp highs, providing a balanced and immersive listening experience. The speaker’s power handling capabilities are robust, with the low-frequency section handling 2×300 W (RMS) and 1200 W (peak), while the high-frequency section manages 2×60 W (RMS) and 240 W (peak). This ensures reliability even during high-demand performances, minimizing distortion and maximizing output efficiency.

Sensitivity is a critical factor in the PL-210’s design. The low-frequency drivers achieve 100 dB (1W@1M), and the high-frequency drivers reach 110 dB (1W@1M), allowing the speaker to produce significant sound pressure levels with minimal power input. This efficiency translates to a maximum sound pressure of 128 dB (peak/1M) for the LF section and 131 dB (peak/1M) for the HF section, ensuring exceptional clarity and impact even in large venues.

The speaker incorporates two 10-inch, 50-core woofers and two 1.75-inch, 44-core tweeters, engineered to handle high power loads while maintaining precision and durability. The woofers deliver punchy mid-bass and low-frequency reproduction, while the tweeters excel in reproducing detailed highs without harshness. With an impedance of 16 ohms for both LF and HF sections, the PL-210 ensures stable performance and compatibility with a wide range of amplifiers.

Coverage is optimized with a 110° horizontal and 10° vertical dispersion pattern, providing consistent sound distribution across the audience area. This controlled directivity minimizes unwanted reflections and ensures that every listener experiences the same audio quality. The cabinet construction utilizes Baltic birch plywood, known for its rigidity and resonance-damping properties. This material enhances the speaker’s overall acoustic performance by reducing cabinet vibrations and coloration.

The PL-210 features two NL4 input jacks, with dedicated connections for LF (1+, 1-) and HF sections, offering flexibility for bi-amping or passive full-range operation. The trapezoidal design of the cabinet allows for precise array alignment, minimizing gaps between enclosures and maintaining coherent wavefront propagation. Each cabinet can be adjusted between 0° and 7.5° in 1° increments, enabling precise vertical splay angles for tailored coverage.

Weighing 26 kg and measuring 700 mm (W) × 311 mm (H) × 439 mm (D), the PL-210 is designed for portability and ease of deployment. Its integrated handles and rugged steel grille provide durability and protection for the drivers. When combined with the DBK PL-21B subwoofer, the system delivers a full-range sound with powerful lows, elastic midrange, and detailed highs, making it suitable for concerts, theaters, and large-scale events.

DBK’s commitment to innovation and quality is evident in the PL-210’s design, which balances compact dimensions with high output capabilities. Whether used alone or as part of a larger array, this speaker exemplifies professional audio excellence.
